Main Technical Parameter
| Description | Automatic Nylon Cage Assembly Machine |
| Scope of application | Bearing outer diameter8-16mm Bearing outer diameter 16-50mm |
| Process flow | Feeding of conveyor belt → Fiber optic point finding → Gathering and dividing of balls → Ball inspection → Placement of Nibao → Placement of holder → Mechanical arm upper protection detection → Unqualified kick out → Placement of holder → Pre pressing → Riveting pressing → Final inspection → Rejection of non-conforming products → Finished product discharge |
| Working voltage | 220V/50Hz/1.5A |
| Working air pressure | 0.4MPa |
| Working Temperature | 10-35ºC |
| Processing Beat | ≤3.2S~4S |
Main Functions:
Automatically complete the entire set of actions;
Feeding mechanism: bearing automatic feeding,cage string rod feeding;
Fiber optic point finding: Automatically find a suitable space for inserting the ball mold,ensuring that the steel ball is undamaged;
Ball distribution mechanism: plug-in ball collection,needle insertion ball distribution;
Ball distribution detection: missing ball,uneven distribution;
Upper retainer feeding: Use a string rod form for feeding,taking one retainer at a time and placing it above the product;
Upper retainer detection: fewer upper retainers, more upper retainers;
Lower retainer loading: Use a string rod form for loading,taking one retainer at a time and placing it underthe product;
Riveting and pressing station: pre bending is carried out by a helical tooth mold,and then formal bending is carried out by a flat tooth mold;
Post press inspection:The bending claw height is not standard,and the cage is deformed,leaking pressure,and the cage is missing;
Equipped with positioning digital display detection and electric touch detection;
The complete machine is easy to replace,meeting the production mode of small batch and multiple varieties;
The special design of the mold that directly contacts the cage and steel ball ensures no damage to the cage and steel ball;
Equipment features:
Fiberopticvacancy finding mechanism;No injury,close the ball
Ball distributor Bull polishing: no damage ball distributor
Multiple testing:ensuring high-quality product output
Double down protection function can be added for installation
Customizable series of error prevention functions
Overall appearance design with hood added
Customized operation direction for the entire machine,suitable forvarious whole line schemes
Show Factory
Related Products
FAQ
Q: Are you a factory or trading company ?
A: We are a factory specializing in manufacturing, R&D, and have our own foreign trade rights and production equipment.
Q: Could you please send me your best price?
A: Yes, we cherish every cooperative customer and work hard to facilitate transactions.And before quoting,please kindly consult us and provide:
What part do you need to fine grind? Your requirements for accuracy.
If there are product drawings, it will be more helpful for us to provide you with a suitable equipment solution.
Q: When is your delivery time ?
A: 90-110 days after 30%-50% deposit received.
Q: When is your payment term ?
A: Payment shall be 30%-50% deposit by T/T,balance 50%-70% paid by T/T,D/P after inspection but before shipment.
Q: Can you make machines based on customer's design ?
A: Yes,we can customized. According to your special request,we can design solution and provide service scheme.
Q: How to handle the installation and test for machine?
A: Our engineers are available to service overseas to install and train local staff.Specific arrangements will be explained clearly in each quotation.
After-sales Service
Technical Support
1.Customised machine;
2.Customized layout drawings;
3.Commissioning and installation before delivery;
4.Overseas engineers to install and debug ,Training ;
5.Formula debugging;
6.Upgrading and transformation, make your equipment back to a better state and solve the problem of insufficient output;
7.24-hour online technical support and service
Spare Parts Service
1.A processing centre for Perishable parts, sent abroad in a second.
2.During the warranty period, we can provide replacement parts free of charge, except in the case of artificially damaged parts.
Maintenance
The seller guarantees the quality of the products for 12 months since the date of installation. During the warranty period, any problems/defaults happen on the hard parts of the machinery, the buyer will replace the parts at the seller's cost (Free). If the defaults are aroused by the defaulted operations, or the buyer needs the technical assistance for the processing problems, the buyer should be responsible for all the cost and their allowance.
Packing and Shipping
Usually shipping by sea, Packed in wooden crates, wooden pallets.
And before we pack, we will apply protective oil on the machine to reduce the contact between the machine and the air.
